Dana Spicer 6.5-40-201 SPLINE Fits 4.5 inch .134 wall tube 3.0 inch Diameter with 16 Splines
6.5-40-201
DANA SPICER 6.5-40-201
Shipping: >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
Pricing:
$212.95
Description
DANA SPICER SPLINE 6.5-40-201
- Fits any series 16 Spline SLIP YOKE designed for 3.0 inch diameter spline
- Fits TUBE DIAMETER = 4.5 inch OUTSIDE TUBE Diameter
- Fits TUBE WALL THICKNESS = .134 inch Tube wall thickness
- Major SPLINE Diameter = 3.000
- SPLINES = 16
- K = 9.469
- L = 4.500
- R = 8.406
CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions
Details
- 6.5-40-201
- 6.5-40-201
- Spicer
- Available
- New
Categories
Shipping Information
- Item Requires Shipping
- 24.0 lbs.
- W7.0000” x H7.0000” x L14.0000”
