Dana Spicer 5-40-1041 SPLINE Fits 3.5 inch .134 wall tube 2.0 inch Diameter with 16 Splines

DANA SPICER SPLINE 5-40-1041

• Fits any series 16 Spline SLIP YOKE designed for 2.0 inch diameter spline
• Fits TUBE DIAMETER = 3.5 inch OUTSIDE TUBE Diameter
• Fits TUBE WALL THICKNESS =  .134 inch Tube wall thickness
• Major SPLINE Diameter = 2.000

• SPLINES = 16

• K = 10.188

• L = 3.500

• R = 9.281
