Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

Dana Spicer 3-54-611 Midship STUB SPLINE 1.375-10 spline fits 1.378 ID bearing fits 3 x .083 wall tube
Part Number:
3-54-611


UPC:
023913235420
Your Cost $148.35 Sale Price $124.24
You Save $24.11
STATUS:  IN STOCK - FREE SHIPPING

DANA SPICER 3-54-611

MIDSHIP STUB SPLINE

Use with 1.378 ID Center Support Bearing

  • 1.375 inch diameter spline
  • 10 SPLINES
    • Fits TUBE DIAMETER = 3.0 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
      • Butt diameter = 2.845
    • Major SPLINE Diameter = 1.375
    • SPLINES = 10
    • STYLE = 2
    • B = 1.719
    • C = 1.378
    • G = 1.125
    • K = 4.0
    • L = 1.688
    • Y = 2.656
    • Thread size = 1.0 - 20
  • SPECIAL NOTES:
    • Requires nut 16-74-101 ...see bottom of this page
    • Use with center bearing 210367-1X  ...see bottom of this page
    • Use with end yoke 3-4-178-1X for 1350 series ...see bottom of this page
    • Use with end yoke 3-4-2851-1X for 1410 series ...see bottom of this page

Spicer
Dana Spicer 3-54-611 Midship STUB SPLINE 1.375-10 spline fits 1.378 ID bearing fits 3 x .083 wall tube
Dana Spicer 3-54-611 Midship STUB SPLINE 1.375-10 spline fits 1.378 ID bearing fits 3 x .083 wall tubing
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK - FREE SHIPPING
YOUR COST:  $148.35 Sale Price $124.24
You Save $24.11

DANA SPICER 3-54-611

MIDSHIP STUB SPLINE

Use with 1.378 ID Center Support Bearing

  • 1.375 inch diameter spline
  • 10 SPLINES
    • Fits TUBE DIAMETER = 3.0 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
      • Butt diameter = 2.845
    • Major SPLINE Diameter = 1.375
    • SPLINES = 10
    • STYLE = 2
    • B = 1.719
    • C = 1.378
    • G = 1.125
    • K = 4.0
    • L = 1.688
    • Y = 2.656
    • Thread size = 1.0 - 20
  • SPECIAL NOTES:
    • Requires nut 16-74-101 ...see bottom of this page
    • Use with center bearing 210367-1X  ...see bottom of this page
    • Use with end yoke 3-4-178-1X for 1350 series ...see bottom of this page
    • Use with end yoke 3-4-2851-1X for 1410 series ...see bottom of this page



CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions
