Dana Spicer 3-53-2381 midship stub 1.437 - 21/22 splines fits 3.5 inch .065 wall tube
Part Number:
3-53-2381


UPC:
023913231446
Your Cost $89.33 Sale Price $75.26
You Save $14.07
STATUS:  FACTORY DIRECT TO YOU

Dana Spicer 3-53-2381

  • midship stub
  • 1.437 - 21 based on 22 splines
  • fits 3.5 inch .065 wall tube
Spicer
Dana Spicer 3-53-2381 midship stub 1.437 - 21/22 splines fits 3.5 inch .065 wall tube
Dana Spicer 3-53-2381 midship stub 1.437 - 21/22 splines fits 3.5 inch .065 wall tube
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY DIRECT TO YOU
YOUR COST:  $89.33 Sale Price $75.26
You Save $14.07

Dana Spicer 3-53-2381

Brand Spicer
For Use With Outboard Slip Yoke
Series 1310-1410
Material Steel
Spline O.D. 1.4370
Number Of Splines 21 based on 22 INVOLUTE
Involute Y
Fits Tube Diameter 3.5 inch
Fits Tube Wall 0.065
Spline End To Brg Shoulder (Y) 7.385
Spline End To Weld (K) In. 8.000
Spline Length (L) In. 3.500
Shoulder Diameter (B) In. 1.812
Shoulder Length (G) In. 0.375
Bearing Diameter (C) In. 1.575
Butt Diameter 3.381
Style 2
Bearing Diameter (Max) 1.5751
Bearing Diameter (Min) 1.5747
Bearing Diameter Length 1.375



Dana Spicer 3-53-2381 midship stub 1.437 - 21/22 splines fits 3.5 inch .065 wall tube

Dana Spicer 3-53-2381 midship stub 1.437 - 21/22 splines fits 3.5 inch .065 wall tube
