Dana Spicer 3-53-1781 Midship STUB SPLINE 1.500-10 spline fits 1.574 ID bearing fits 3 x .083 wall tube

DANA SPICER 3-53-1781

MIDSHIP STUB SPLINE

Use with 1.574 ID Center Support Bearing

• 1.500 inch diameter spline
• 10 SPLINES

  • Fits TUBE DIAMETER = 3.0 inch OUTSIDE TUBE Diameter
  • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
    • Butt diameter = 2.845
  • Major SPLINE Diameter = 1.500
  • SPLINES = 10
  • STYLE = 2
  • B = 1.810
  • C = 1.574
  • G = .875

  • K = 3.875

  • L = 1.940
  • Y = 2.750
  • Thread size = 1.0 - 20
• SPECIAL NOTES:
  • Requires nut 16-74-101 ...see bottom of this page

  • Use with center bearing 210873-1X  ...see bottom of this page
  • Use with end yoke 3-4-6561-1 for 1410 series ...see bottom of this page
