Dana Spicer 3-53-07832 MIDSHIP SPLINE Fits 3.5 inch .083 wall tube 1.562 inch Diameter with 16 Splines

SKU: 3-53-07832

DANA SPICER 3-53-07832

Limited Supply: only 1 remaining

Pricing: $146.95

Description

DANA SPICER 3-53-07832

MIDSHIP SPLINE
Use with Center Support Bearing
Fits any series 16 Spline SLIP YOKE designed for 1.562 inch diameter spline
- Fits TUBE DIAMETER = 3.5 inch OUTSIDE TUBE Diameter
- Fits TUBE WALL THICKNESS = .083 inch Tube wall thickness
- Major SPLINE Diameter = 1.562
- SPLINES = 16
- STYLE = 2
- B = 1.940
- C = 1.575
- G = .810
- K = 8.578
- L = 3.000
- Y = 7.470
SPECIAL NOTES:
- Blue GLIDECOAT on Spline for smooth operation and long life (DO NOT REMOVE this coating)
- Replaces Dana Spicer 5007832
