Dana Spicer 2-53-1511 MIDSHIP SPLINE Fits 3.0 inch .083 wall tube 1.375 inch Diameter with 15/16 Splines
Part Number:
2-53-1511


UPC:
023913278083
Your Cost $142.30
Sorry, sold out
STATUS:  FACTORY BACK ORDER at this time

DANA SPICER 2-53-1511

  • MIDSHIP SPLINE
  • Use with Center Support Bearing


Spicer
Dana Spicer 2-53-1511 MIDSHIP SPLINE Fits 3.0 inch .083 wall tube 1.375 inch Diameter with 15/16 Splines
Dana Spicer 2-53-1511 MIDSHIP SPLINE Fits 3.0 inch .083 wall tubing 1.375 inch Diameter with 15/16 Splines
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY BACK ORDER at this time
YOUR COST:  $142.30

DANA SPICER 2-53-1511

  • MIDSHIP SPLINE
  • Use with Center Support Bearing
  • Fits any series 15 Based on 16 Spline SLIP YOKE designed for 1.375 inch diameter spline
    • Fits TUBE DIAMETER = 3.0 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
    • Major SPLINE Diameter = 1.375
    • SPLINES = 15/16
    • STYLE = 2
    • B = 1.688
    • C = 1.378
    • G = .810
    • K = 9.540
    • L = 3.500
    • Y = 8.480
  • SPECIAL NOTES:
    • Blue GLIDECOAT on Spline for smooth operation and long life (DO NOT REMOVE this coating)
    • May use boot 211932X, order seperate



CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions

Dana Spicer 2-53-1511 MIDSHIP SPLINE Fits 3.0 inch .083 wall tube 1.375 inch Diameter with 15/16 Splines

Dana Spicer 2-53-1511 MIDSHIP SPLINE Fits 3.0 inch .083 wall tubing 1.375 inch Diameter with 15/16 Splines

You May Also Need These Parts to Complete the Job

DANA SPICER 211932X Rubber Dust Boot 1.140 ID x 1.670 ID x 5.030 inches long 4 Bellows for spline and slip yoke style driveshaft fits 1210, 1310 and 1330 series
$17.82
