Dana Spicer 2-53-1191 Midship STUB SPLINE 1.375-10 spline fits 1.378 ID bearing fits 2.5 x .083 wall tube
2-53-1191
DANA SPICER 2-53-1191
MIDSHIP STUB SPLINE
Use with 1.378 ID Center Support Bearing
- 1.375 inch diameter spline
- 10 SPLINES
- Fits TUBE DIAMETER = 2.5 inch OUTSIDE TUBE Diameter
- Fits TUBE WALL THICKNESS = .083 inch Tube wall thickness
- Butt diameter = 2.345
- Major SPLINE Diameter = 1.375
- SPLINES = 10
- STYLE = 2
- B = 1.688
- C = 1.378
- G = .812
- K = 3.750
- L = 1.781
- Y = 2.688
- Thread size = 1.0 - 20
- SPECIAL NOTES:
- Requires nut 16-74-101 ...see bottom of this page
- Use with center bearing 210090-1X
- Use with end yoke 2-4-2671-1
- Requires nut 16-74-101 ...see bottom of this page
Limited Supply: only 3 remaining
Pricing:
$120.95
Description
DANA SPICER 2-53-1191
MIDSHIP STUB SPLINE
Use with 1.378 ID Center Support Bearing
- 1.375 inch diameter spline
- 10 SPLINES
- Fits TUBE DIAMETER = 2.5 inch OUTSIDE TUBE Diameter
- Fits TUBE WALL THICKNESS = .083 inch Tube wall thickness
- Butt diameter = 2.345
- Major SPLINE Diameter = 1.375
- SPLINES = 10
- STYLE = 2
- B = 1.688
- C = 1.378
- G = .812
- K = 3.750
- L = 1.781
- Y = 2.688
- Thread size = 1.0 - 20
- SPECIAL NOTES:
- Requires nut 16-74-101 ...see bottom of this page
- Use with center bearing 210090-1X
- Use with end yoke 2-4-2671-1
- Requires nut 16-74-101 ...see bottom of this page
CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions
Details
- 2-53-1191
- 2-53-1191
- Spicer
- Available
- New
Categories
Shipping Information
- Item Requires Shipping
- 4.0 lbs.
- W4.0000” x H4.0000” x L6.0000”
- FREE SHIPPING ON PARTS ORDERS OVER $99
