DT Components DRK-321CMK Master Bearing kit fits GM 8.6 inch 10 bolt REAR end 1998 to 2008
DRK-321CMK
Part Number: DRK321CMK
DRK-321CMK Master Differential Bearing and Seal Kit - DT Components
Fits Chevy, GMC - 8.6 inch 10 bolt REAR end
- Fits CHEVY, GMC 8.6 inch 10 bolt REAR end
- 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008
Limited Supply: only 2 remaining
Pricing:
$172.95
Description
Part Number: DRK321CMK
DRK-321CMK Master Differential Bearing and Seal Kit - DT Components
Fits Chevy, GMC - 8.6 inch 10 bolt REAR end
- Fits CHEVY, GMC 8.6 inch 10 bolt REAR end
- 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008
Parts in this kit
- (2) Differential Bearing: LM603049 - LM603012
- (1) Pinion Head Bearing: STD4183KELFT
- (1) Pinion Tail Bearing: M88048 - M88010
- (1) Pinion Seal: 710506 (2.088 x 2.763)
- (1) Crush Sleeve: CS321
- (1) Pinion Nut: PN3
- (1) Gear Marking & Brush: GMC1-BR1
- (1) Threadlocker: TL1
- (1) Sealer RTV Silicone
- (1) Pinion Depth Shims: SK4
- (1) Differential Shims: SK7
- (10) Ring Gear Bolts: RGB2
