DT Components DRK-334MK Master Bearing Kit fits Dana 30 Front 1971 to 2000 various Jeep models

Part Number: DRK334MK

DRK-334MK Master Differential Bearing and Seal Kit - DT Components

• DRK-334MK Fits Jeep Dana 30 FRONT
  • Jeep Cherokee XJ Front
    • 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999
  • Jeep Cherokee XJ Front with Dana 30 High Pinion
    • 2000
  • Jeep Wagoneer SJ Front
    • 1971, 1972, 1973
  • Jeep Wagoneer XJ Front
    • 1984, 1985, 1986, 1987, 1988, 1989
  • Jeep CJ5 Front
    • 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983
  • Jeep CJ7 Front
    • 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986
  • Jeep Scrambler CJ8 Front
    • 1981, 1982, 1983, 1984, 1985
  • Jeep Comanche Front
    • 1986, 1987, 1988, 1989, 1990, 1991, 1992
  • Jeep Jeepster Front
    • 1971, 1972, 1973
  • Jeep Wrangler YJ Front
    • 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995

Parts in this kit

(2) Differential Bearing: LM501349 - LM501314
(1) Pinion Head Bearing: HM88649 - HM88610
(1) Pinion Tail Bearing: 02872 - 02820
(1) Pinion Seal: 5778 (1.552 x 3.160)
(1) Pinion Nut: PN8F
(1) Gear Marking & Brush: GMC1-BR1
(1) Threadlocker: TL1
(1) Sealer RTV Silicone

(1) Pinion Bearing Shims: SK5
(1) Pinion Depth Shims: SK54
(1) Differential Bearing Shims: SK20
(10) Ring Gear Bolts: RGB5
