DT Components DRK-334TJMK Master Bearing Kit fits Dana 30 Front Jeep Wrangler TJ 1997 to 2006, XJ Cherokee 2000 - 2001, Grand Cherokee 1997 - 1998

Part Number: DRK334TJMK

DRK-334TJMK Master Differential Bearing and Seal Kit - DT Components

• Fits Jeep Wrangler TJ Dana 30 FRONT
  • 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006
• Fits Jeep Cherokee XJ Dana 30 LOW Pinion FRONT
  • 2000, 2001
• Fits Jeep Grand Cherokee Dana 30 FRONT
  • 1997, 1998

Parts in this kit

(2) Differential Bearing: LM501349 - LM501314
(1) Pinion Head Bearing: HM88649 - HM88610
(1) Pinion Tail Bearing: M86649 - M86610
(1) Pinion Seal: 5778 (1.552 x 3.160)

(1) Pinion Seal: 50660 (1.552 x 3.160)

(1) Crush Sleeve: CS335
(1) Pinion Nut: PN8F
(1) Gear Marking & Brush: GMC1-BR1
(1) Threadlocker: TL1
(1) Sealer RTV Silicone
(1) Pinion Depth Shims: SK54
(1) Differential Bearing Shims: SK20
(10) Ring Gear Bolts: RGB5

(1) Slinger: 13575
