Dana Spicer 72706-3X INNER AXLE Drivers Side 15 Splines fits 1985 to 1987 DODGE W150, W200, W250 with DANA 44 Disconnect Front Axle - OBSOLETE

Diagram Number: 85-IN

72706-3X

DANA SPICER 72706-3X

  • INNER AXLE SHAFT - DRIVERS SIDE
    • Fits 1985, 1986, 1987 DODGE W150, W200, W250 with DANA 44 Disconnect front axle
      • CHECK to be sure Dimension C = 19.19 inches on original axle shaft

72706-3X is OBSOLETE and NO LONGER Available



IMPORTANT NOTES:

  • 73579-1X DOES NOT FIT 1985 TO 1987 with the bearing and seal at the end of the left side housing tube.
  • 73579-1X DOES NOT have the machined bearing surface required on the 1985 to 1987



Not Available
Pricing: $0.00

Description

DANA SPICER 72706-3X

  • INNER AXLE SHAFT - DRIVERS SIDE
    • Fits 1985, 1986, 1987 DODGE W150, W200, W250 with DANA 44 Disconnect front axle
      • CHECK to be sure Dimension C = 19.19 inches on original axle shaft

72706-3X is OBSOLETE and NO LONGER Available



IMPORTANT NOTES:

  • 73579-1X DOES NOT FIT 1985 TO 1987 with the bearing and seal at the end of the left side housing tube.
  • 73579-1X DOES NOT have the machined bearing surface required on the 1985 to 1987



DIMENSIONS

  • 15 SPLINES
  • C1 = 1.59 inch diameter with 15 splines
  • C = 19.19 inches Centerline of u-joint to end of yoke
  • Requires 5-760X Axle Universal Joint
    • U-Joint Snap Ring Dimension = 2.188 inches ( 2 3/16 inches )
    • U-Joint Bearing Cap Diameter = 1.188 inches ( 1 3/16 inches )
"

Details

  • 72706-3X
  • 72706-3X
  • Spicer
  • 0
  • 0
  • 85-IN
  • Temporarily Not Available
  • New

Categories

Shipping Information

  • Item Requires Shipping
  • 11.0 lbs.
  • W6.0000” x H5.0000” x L21.0000”
