DANA SPICER SPL70-4X Front Axle Universal Joint GREASEABLE 3.780 lockup dimension fits replacement axle part numbers 10013778, 10013781

DANA SPICER SPL70-4X

Dana SUPER 60 Front Axle U-joint

• GREASEABLE front axle universal joint ...grease fitting in body
• Fits replacement axle part numbers 10013778, 10013781

  • You must measure your original axle u-joint to determine which replacement u-joint to choose.

SPL70-4X DIMENSIONS

• C & D = 1.375 inch diameter with inside "C" Clips to lock the cap in place.
• A & B = 3.780 inches is the span between the yoke inner surfaces where the "C" Clips lock in.
• 1550WJ series

SPL55-3X and SPL55-4X DIMENSIONS ARE DIFFERENT

• C & D = 1.375 inch diameter with inside "C" Clips to lock the cap in place.
• A & B = 3.0 inches is the span between the yoke inner surfaces where the "C" Clips lock in.
• 1480WJ series
