SONNAX T35-ALFY-10 Adapter flange yoke 6 bolt Fits Ford Mustang with 93mm bolt circle dia. pinion flange (automatic 2015??019)
SONNAX T35-ALFY-10
6-Bolt Adapter Flange Yoke Kit
- Fits Ford Mustang with 93mm bolt circle dia. pinion flange (automatic 2015–2019).
Sonnax 6-bolt adapter flange yoke kit T35-ALFY-10 is an ideal upgrade for 2015–2019 Ford Mustang driveshafts. Specifically designed to bolt up to 93mm bolt circle diameter pinion flanges, the Sonnax yoke allows elimination of the OE CV joint. When used with a stub and slip assembly, it makes it easy to also eliminate the rubber giubo or "flex" joint, converting a two-piece driveshaft into a one-piece, U-joint style driveline.
- :
- Sonnax flange yoke kit T35-ALFY-10 is a custom part and may fit more models than noted above. Measure flange O.D., output flange bolt holes and bolt circle diameter to determine if this yoke is appropriate for your build.
- Flange yoke
- Bolts (6)
- Washers (6)
- U-Joint Series: 1350
- Pilot Type: M
- Material: 6061-T6 Aluminum
- Bolt Hole Dia.: 0.438"
- Flange Face to Centerline: 3.440"
- Weight: 1.800lbs
- Flange Outer Dia.: 4.590"
- Pilot Dia.: 4.328"
- Bolt Count: 6
- Bolt Circle Dia.: 93mm
Description
SONNAX T35-ALFY-10
6-Bolt Adapter Flange Yoke Kit
- Fits Ford Mustang with 93mm bolt circle dia. pinion flange (automatic 2015–2019).
Sonnax 6-bolt adapter flange yoke kit T35-ALFY-10 is an ideal upgrade for 2015–2019 Ford Mustang driveshafts. Specifically designed to bolt up to 93mm bolt circle diameter pinion flanges, the Sonnax yoke allows elimination of the OE CV joint. When used with a stub and slip assembly, it makes it easy to also eliminate the rubber giubo or "flex" joint, converting a two-piece driveshaft into a one-piece, U-joint style driveline.
- :
- Sonnax flange yoke kit T35-ALFY-10 is a custom part and may fit more models than noted above. Measure flange O.D., output flange bolt holes and bolt circle diameter to determine if this yoke is appropriate for your build.
- Flange yoke
- Bolts (6)
- Washers (6)
- U-Joint Series: 1350
- Pilot Type: M
- Material: 6061-T6 Aluminum
- Bolt Hole Dia.: 0.438"
- Flange Face to Centerline: 3.440"
- Weight: 1.800lbs
- Flange Outer Dia.: 4.590"
- Pilot Dia.: 4.328"
- Bolt Count: 6
- Bolt Circle Dia.: 93mm
Details
- T35-ALFY-10
- T35-ALFY-10
- SONNAX
- Temporarily Not Available
- New
Shipping Information
- Item Requires Shipping
- 5.0 lbs.
- W8.0000” x H8.0000” x L8.0000”
