NEAPCO N3-23-9163X Transfer Case Slip yoke CV FLANGE Style for NP 205, 208, 241 with 32 splines
Part Number:
N3-23-9163X


UPC:
Your Cost $213.10
Sorry, sold out
STATUS:  DISCONTINUED ITEM

NEAPCO N3-23-9163X

Transfer Case Slip Yoke 32 spline Flange Style for New Process NP205, 208, 241 .

Neapco
NEAPCO N3-23-9163X Transfer Case Slip yoke CV FLANGE Style for NP 205, 208, 241 with 32 splines
NEAPCO N3-23-9163X Transfer Case Slip yoke CV FLANGE Style for NP 205, 208, 241 with 32 splines
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  DISCONTINUED ITEM
YOUR COST:  $213.10

NEAPCO N3-23-9163X

Transfer Case Slip Yoke 32 spline Flange Style for New Process NP205, 208, 241

Great for adding a CV to the rear output of the stock NP 208, 241 New Process Transfer case

Designed to handle a 4 inch lift

Bolt Pattern and pilot diameter designed to accept GM Flange Yokes...see bottom of this page for available flange yokes to connect to this slip yoke.

  • Barrel Diameter... Dimension = 1.886 inches
  • Barrel Length... Dimension =  6 inches
  • Series... Can be used with 3R, 1330 and 1350 series CV Flange Yokes
  • Spline count... 32
  • Flange has 4 threaded holes and comes with 4 Grade 8 Allen Head bolts to mount flange
  • Bolt Pattern.... 4.25 inches measured diagonally
  • Pilot Diameter... 3.125 inches (3 1/8 inches)

Can be used with a single u-joint Flange Yoke or a CV Flange Yoke in GM 3R Series, 1330 series or 1350 series.   See bottom of this page for flange yokes.



NEAPCO N3-23-9163X Transfer Case Slip yoke CV FLANGE Style for NP 205, 208, 241 with 32 splines

NEAPCO N3-23-9163X Transfer Case Slip yoke CV FLANGE Style for NP 205, 208, 241 with 32 splines

Click to Load this Photo
Click Here to Enlarge
Click to Load this Photo
Click Here to Enlarge

Enter your email address and we'll send you a message when this item is available

Please enter your email address in order to be notified when this item is available.
