Neapco N4-2-669 Flange Yoke 1550 series 3.750 male pilot
N4-2-669
Neapco N4-2-669 Flange Yoke 1550 Series
Availability: >>>>> SPECIAL ORDER
PART: This part
number is special
ordered from the
factory and shipped
direct to you. It
is NOT Cancellable
and NOT Returnable.
Please make your
selection
carefully!
<<<<<
Pricing:
$128.95
Description
Neapco N4-2-669 Flange Yoke
1550 Series Flange Yoke
- A - Flange or Swing Diameter = 5.774 inches
- B - Bolt Circle Diameter = 4.750 inches
- Bolt Hole Diameter = 0.500 inches
- Bolt Holes = 4
- Bolt Holes = DRILLED
- Bolt Hole Pattern: Rectangle
- Joint Angle (degrees): 22.000
-
Length Between Holes Y: 3.053
-
Length Between Holes X: 3.639
- C - Center Pilot Hole Diameter = 3.750 inches
- Center Pilot = MALE
- Series = 1550
- Outside Snap Ring Style
- U-Joint Width between snap rings = 4.964 inches
- D - U-Joint Bearing cap diameter = 1.375 inches
- G - Center of u-joint bore to Face of flange = 2 inches
Details
- N4-2-669
- N4-2-669
- NEAPCO - FACTORY DIRECT
- >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
- New
Categories
Shipping Information
- Item Requires Shipping
- 3.6 lbs.
- W6.0000” x H4.0000” x L6.0000”
- FREE SHIPPING ON PARTS ORDERS OVER $99
