Dana Spicer 10016266 Transfer Case Yoke 32 spline 1310 series Double Cardan CV style fits 2007 to 2018 JEEP Wrangler JK fits FRONT and REAR output

DANA SPICER 10016266

• CV End Yoke
• 1310 Series
• 32 splines
• 1.875 inch Seal Surface Diameter
• 4.00 inches CL to END
• Fits front output on transfer case Jeep JK
  • 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018

Use this 1310 series CV end yoke to mount a 1310 series double cardan CV driveshaft onto transfer case front output.

Replaces stock OEM transfer case front companion flange designed for ball style high speed CV joint

• You will also need Dana Spicer 2-2-1949 flange yoke to mount a 1310 series driveshaft at the front diff end.
• With part numbers 2-2-1949 and 10016266 you can install a normal 1310 series double cardan CV driveshaft into your 2007 to 2015 Jeep JK
• Maximum suspension lift to use these parts is no more than 4 inches.

Dana Spicer 10016266 replaces old number 10016921
