Dana Spicer 10024007 Front Hub assembly with bearings, seal, studs and ABS tone ring for Ultimate Dana 60
10024007
Dana Spicer 10024007
Front Hub assembly with bearings, seal, studs and ABS tone ring
Fits Ultimate Dana 60 front ONLY
- 4.785 inch wheel hub pilot
- For use with Spindle part number 10024010 ...see bottom of page
- 3.250 inch Internal spline diameter
- 55 Internal splines
INCLUDES
- 2023571 wheel HUB
- 10020918 wheel studs (8) 9/16 - 18 thread
- 10024008 Bearings set
- 48816 Seal replaces old number 37729
- 2023673 ABS tone ring
Factory assembled with studs, tone ring and bearing races.
Not Available
Pricing:
$438.34
Description
Dana Spicer 10024007
Front Hub assembly with bearings, seal, studs and ABS tone ring
Fits Ultimate Dana 60 front ONLY
- 4.785 inch wheel hub pilot
- For use with Spindle part number 10024010 ...see bottom of page
- 3.250 inch Internal spline diameter
- 55 Internal splines
INCLUDES
- 2023571 wheel HUB
- 10020918 wheel studs (8) 9/16 - 18 thread
- 10024008 Bearings set
- 48816 Seal replaces old number 37729
- 2023673 ABS tone ring
Factory assembled with studs, tone ring and bearing races.
Details
- 10024007
- 10024007
- 023913466282
- Spicer
- Temporarily Not Available
- New
Categories
- JEEP 4X4 Front and Rear - DANA 60 JK Ultimate Builder Parts - HUB and SPINDLE
- JEEP REAR ENDS - DANA 60 JK Ultimate Builder Parts - HUB and SPINDLE
- AXLES and FRONT DIFF Parts 4X4 - JEEP 4X4 Front and Rear - DANA 60 JK Ultimate Builder Parts
- REAR AXLES and DIFFERENTIAL PARTS - DANA 60 JK Ultimate Builder Parts - HUB and SPINDLE
Shipping Information
- Item Requires Shipping
- 22.0 lbs.
- W11.0000” x H9.0000” x L15.0000”
