Dana Spicer 211848-1X Center Support Bearing .437-14 threaded bolt holes 1.574 ID fits Dodge B150, B1500, B250, B350, B3500, Ram 1500, 2500, 3500 and 1500, 2500, 3500 VAN

211848-1X

DANA SPICER 211848-1X

Center Support Bearing for 2 piece driveshaft

  • Scroll down for application information

Fits SPLINE OD = 1 1/2 inch

  • CENTER SUPPORT BEARING
    • RUBBER MOUNTED
  • A = ID of Bearing = 1.574 inches
  • B = CL to MOUNTING SURFACE = 3.250 inches
  • C = BRACKET WIDTH = 1.742 inches
  • D = MOUNTING HOLE Dimension = 3.380 inches
    • MOUNTING hole diameter = Threaded for .437 - 14

REPLACES

  • 4773014
  • TIMKEN HB88108D

Limited Supply: only 2 remaining
Pricing: $89.76

Customize Your Item

- -
 * required
Qty:

Description

DANA SPICER 211848-1X

Center Support Bearing for 2 piece driveshaft

  • Dodge B150, B250, B350 - 1994
  • Dodge B1500 - 1995, 1996, 1997, 1998
  • Dodge B3500 - 1995, 1996, 1997, 1998
  • RAM 1500 - 1994, 1995, 1996, 1997, 1998, 1999
  • RAM 1500 VAN - 1999
  • RAM 2500 - 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002
  • RAM 2500 VAN - 1999, 2000, 2001, 2002
  • RAM 3500 - 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001
  • RAM 3500 VAN - 1999, 2000, 2001

Fits SPLINE OD = 1 1/2 inch

  • CENTER SUPPORT BEARING
    • RUBBER MOUNTED
  • A = ID of Bearing = 1.574 inches
  • B = CL to MOUNTING SURFACE = 3.250 inches
  • C = BRACKET WIDTH = 1.742 inches
  • D = MOUNTING HOLE Dimension = 3.380 inches
    • MOUNTING hole diameter = Threaded for .437 - 14

Dana Spicer 211848-1X dimensions at Denny's Driveshafts



Details

  • 211848-1X
  • 211848-1X
  • Spicer
  • Available
  • New

Categories

Shipping Information

  • Item Requires Shipping
  • 5.0 lbs.
  • W10.0000” x H10.0000” x L3.0000”
