Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

NEAPCO N2-3-9165KX Driveshaft Slip Yoke 1310 series 1.375 - 31 based on 32 splines 7.38 inches
Part #:
N2-3-9165KX
Your Cost $71.95

NEAPCO N2-3-9165KX

1310 series Slip Yoke

  • Fits Front or Rear Spline and Slip Style Driveshaft
  • 31 based on 32 splines ( one wide spline for alignment )
  • 1.375 inch Spline Diameter
  • 7.38 inches from center of u-joint bearing cap to end of yoke with seal removed.

Neapco
NEAPCO N2-3-9165KX Driveshaft Slip Yoke 1310 series 1.375 - 31 based on 32 splines 7.38 inches
NEAPCO N2-3-9165KX Driveshaft Slip Yoke 1310 series 1.375 - 31 based on 32 splines 7.38 inches
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $71.95

NEAPCO N2-3-9165KX

1310 series Slip Yoke

  • Fits Front or Rear Spline and Slip Style Driveshaft
  • 31 based on 32 splines ( one wide spline for alignment )
  • 1.375 inch Spline Diameter
  • 7.38 inches from center of u-joint bearing cap to end of yoke with seal removed.



Designed for 1310 series u-joint.  See bottom of this page for 1310 series u-joints

    • 3 7/32 inches between snap rings
    • 1 1/16 diameter bearing caps
    • For proper fit be sure to Measure OUTSIDE DIAMETER of SPLINED SHAFT
    • Spline Drawing copyright Denny's Driveshafts
    • Includes Screw on seal
    • 7.38 inches from center of u-joint bearing cap to end of yoke with seal removed.
      • Measure from CENTER of Bearing Cap Hole to END of Yoke with seal removed
      • Slip Yoke Drawing copyright Denny's Driveshafts









NEAPCO N2-3-9165KX Driveshaft Slip Yoke 1310 series 1.375 - 31 based on 32 splines 7.38 inches

NEAPCO N2-3-9165KX Driveshaft Slip Yoke 1310 series 1.375 - 31 based on 32 splines 7.38 inches

Click to Load this Photo
Click Here to Enlarge
Click to Load this Photo
Click Here to Enlarge
