Dana Spicer 211913XKT 1330 Double Cardan CV Head Assembly KIT fits 1995 to 2005 Dodge Ram with 4.25 inch bolt circle and 3.125 inch pilot on front transfer case flange

Dana Spicer 211913XKT

Double Cardan CV KIT

• Fits 1995 to 2005 Dodge RAM OEM and aftermarket 1330 series FRONT driveshafts that are built with a NON greaseable stud yoke.
  • DOES NOT FIT any greaseable style 1330 series stud yokes
• Fits transfer case output flange with 4.25 inch bolt circle and 3.125 inch pilot diameter
• 1330 Series NON Greaseable Center yoke
  • Needle Bearing Ball Socket fits 1/2 inch stud yoke
• Assembled as shown in photo

INCLUDES

• (1) 211913X ...Dana Spicer 1330 NON Greaseable CV centering yoke
• (1) 2-26-527 ...Dana Spicer 1330 H-Yoke
• (2) 5-1330X ...Dana Spicer 1330 Greaseable universal Joints
• (1) 2-86-418 ...Dana Spicer Rubber Boot

DIMENSIONS

• Bolt Circle.... 4.25 inches measured diagonally
• Pilot Diameter... 3.125 inches
• Fits universal joint 3.625 inches cap to cap (3 5/8 inches)
• Fits u-joint bearing cap diameter 1.062 inches (1 1/16 inches)
