Dana Spicer 3-53-1791 Midship STUB SPLINE 1.500-10 spline fits 1.574 ID bearing fits 3.5 x .083 wall tubing
Part #:
3-53-1791
Your Cost $86.44

DANA SPICER 3-53-1781

MIDSHIP STUB SPLINE

Use with 1.574 ID Center Support Bearing

  • 1.500 inch diameter spline
  • 10 SPLINES
    • Fits TUBE DIAMETER = 3.0 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
      • Butt diameter = 2.845
    • Major SPLINE Diameter = 1.500
    • SPLINES = 10
    • STYLE = 2
    • B = 1.810
    • C = 1.574
    • G = .875
    • K = 3.875
    • L = 1.940
    • Y = 2.750
    • Thread size = 1.0 - 20
  • SPECIAL NOTES:
    • Requires nut 16-74-101 ...see bottom of this page
    • Use with center bearing 210873-1X  ...see bottom of this page
    • Use with end yoke 3-4-6561-1 for 1410 series ...see bottom of this page
    • Use with end yoke 3-4-6901-1 for 1480 series ...see bottom of this page

Spicer
Dana Spicer 3-53-1791 Midship STUB SPLINE 1.500-10 spline fits 1.574 ID bearing fits 3.5 x .083 wall tubing
Dana Spicer 3-53-1791 Midship STUB SPLINE 1.500-10 spline fits 1.574 ID bearing fits 3.5 x .083 wall tubing
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  SOLD OUT...More Coming Soon
YOUR COST:  $86.44

DANA SPICER 3-53-1791

MIDSHIP STUB SPLINE

Use with 1.574 ID Center Support Bearing

  • 1.500 inch diameter spline
  • 10 SPLINES
    • Fits TUBE DIAMETER = 3.5 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
      • Butt diameter = 3.345
    • Major SPLINE Diameter = 1.500
    • SPLINES = 10
    • STYLE = 2
    • B = 1.810
    • C = 1.574
    • G = .890
    • K = 3.880
    • L = 1.940
    • Y = 2.750
    • Thread size = 1.0 - 20
  • SPECIAL NOTES:
    • Requires nut 16-74-101 ...see bottom of this page
    • Use with center bearing 210873-1X  ...see bottom of this page
    • Use with end yoke 3-4-6561-1 for 1410 series ...see bottom of this page
    • Use with end yoke 3-4-6901-1 for 1480 series ...see bottom of this page



CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions
