AAM 40006885 Front Driveshaft Yoke shaft 3R Series for NP 246, NP261, NP263 Transfer Case 1999 and newr GM 4x4

AAM 40006885

• Fits front output on 1999 and newer GM 4x4 trucks with NP246, NP261, NP263 transfer case
• 3R series Yoke Shaft fits front driveshaft

• GM-K series 4X4s 1998 through 2007
• Hummer H2 2003 through 2007
• GM-G series Vans 2003 through 2006

• 1.378 - 32 splines
• Designed for 3R Series universal joint...see bottom of this page for u-joints
• Requires rubber boot to seal transfer case output...see bottom of this page for rubber boot
• Dimensions
  • 7 5/8 inches from center of u-joint to end of spline
  • 3 1/2 inches of spline
  • 1 3/8 inch spline diameter
  • 2.556 inches between flats where INSIDE "C" clip locks 3R Series universal joint in place
  • 1 1/8 inch bores to fit 3R series Universal joint bearing cap
