Dana Spicer 2-4-1741 end yoke 1310 SERIES 14 splines
2-4-1741
Dana Spicer 2-4-1741
End yoke
- 1310 Series
- 14 Splines
- outside snap ring style
Pricing:
$124.95
Description
Dana Spicer 2-4-1741
End yoke
- 1310 Series
- 14 Splines
- outside snap ring style
| Brand | Spicer |
| Series | 1310 - 3.219 x 1062 |
| Spline Count | 14 |
| Yoke Style | Outside Snap Ring |
| Hub Diameter R | 2.120 |
| C/L To End Hub S | 2.562 |
| Type | Splined Hole |
| Outside Yoke Dimension (In) E | 3.469 |
| Yoke Bearing Dimension (In) D | 1.062 |
| Major Diameter | 1.268 |
| Involute Spline | I |
| Length Thru Hole Q | 1.500 |
| Material | Steel |
| Joint Angle | 17 |
Details
- 2-4-1741
- 2-4-1741
- Spicer
- Available
- New
Categories
Shipping Information
- Item Requires Shipping
- 2.0 lbs.
- W4.0000” x H3.0000” x L4.0000”
- FREE SHIPPING ON PARTS ORDERS OVER $99
