Dana Spicer 2-70-18X Strap and Bolt set fits 1.062 bearing cap diameter 1.587 CL on 1310 and 1330 Dana Spicer pinion yokes and transfer case yokes

DANA SPICER 2-70-18X

• Fits 1.062 cap x 1.587 CL

Strap and Bolt Set

• Fits all Dana Spicer 1310 and 1330 series strap and bolt style pinion yokes and transfer case yokes
• Fits Dodge trucks with Dana 44, Dana 60, Dana 61, Dana 70 strap and bolt style pinion yokes and transfer case yokes.
• Comes with (2) steel straps and (4) bolts
• CENTER to CENTER of BOLT HOLES:  1.587
  • BE SURE your yoke has 4 threaded holes and 2 locating tabs

Be sure to replace your existing strap and bolt set to eliminate the chance of the u-joint cap rotating in the pinion yoke and permanently damaging it.  When this happens the damage to the pinion yoke usaully allows the universal joint to move from side to side within the yoke and the resulting looseness will surely cause a nagging vibration. The strap is designed to conform to the shape of the universal joint bearing cap when the bolts are tightened to the proper torque spec and is also designed to apply the proper amount of pressure to hold the bearing cap from rotating within the yoke.  Reusing the straps many times will lessen their ability to apply the right holding pressure....this is why you should replace them...it's much cheaper and easier to replace than a new pinion yoke.
