DANA SPICER 212007X Rubber Dust Boot 1.360 ID x 2.030 ID x 4.140 inches long 3 Bellows for spline and slip yoke style driveshaft fits 1410 and 1480 series 4.14 inches long

DANA SPICER 212007X

Rubber Dust Boot for spline and slip style driveshaft

• Comes with two clamps to firmly attach boot to slip yoke and to spline shaft
• Normally found on 1410 and 1480 series driveshafts
• Fits 1.564 inch diameter splines
• 3 Bellows

CLAMP DIMENSIONS

• 231438-27 LARGE END CLAMP = 2.35 compressed to 2.48 uncompressed
• 231438-26 SMALL END CLAMP= 1.67 compressed to 1.79 uncompressed

BOOT DIMENSIONS

• Large ID = 2.03
• Small ID = 1.36
• Length = 4.14
