Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

Dana Spicer 5-1330-1X Greaseable u-joint 1330 Series fits 1979 to 1999 Ford F350 FRONT CV DRIVESHAFT 1.062 Bearing Caps
Part #:
5-1330-1X
Your Cost $23.00

DANA SPICER 5-1330-1X

UNIVERSAL JOINT

  • Fits FORD F350 FRONT Double Cardan CV Driveshaft
    • 1979, 1980, 1981, 1982,1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999
    • Fits double cardan CV ... (2) u-joints required
  • 1330 Series
  • GREASEABLE U-Joint
  • Grease fitting in u-joint CAP

DIMENSIONS

  • A = 3.625 inches (3 5/8 inches )
  • B = 3.625 inches (3 5/8 inches )
  • C = 1.062 inch ( 1 1/16 inch ) diameter
  • D = 1.062 inch ( 1 1/16 inch ) diameter
  • Outside snap rings

CLICK HERE for Dana Spicer 5-213X with grease fitting in BODY

NOTE: 5-1330-1X universal joint may also fit at the front diff end of your front CV driveshaft.

  • Please measure the front diff pinion yoke carefully to see if the yoke saddles are machined for 1.062 inch u-joint bearing caps or 1.125 inch bearing caps.  Both choices are possible in 1979 to 1999 F350 trucks.




Spicer
Dana Spicer 5-1330-1X Greaseable u-joint 1330 Series fits 1979 to 1999 Ford F350 FRONT CV DRIVESHAFT 1.062 Bearing Caps
Dana Spicer 5-1330-1X Greaseable u-joint 1330 Series fits 1979 to 1999 Ford F350 FRONT CV DRIVESHAFT
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $23.00

DANA SPICER 5-1330-1X

UNIVERSAL JOINT

  • Fits FORD F350 FRONT Double Cardan CV Driveshaft
    • 1979, 1980, 1981, 1982,1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999
    • Fits double cardan CV ... (2) u-joints required
  • 1330 Series
  • GREASEABLE U-Joint
  • Grease fitting in u-joint CAP

DIMENSIONS

  • A = 3.625 inches (3 5/8 inches )
  • B = 3.625 inches (3 5/8 inches )
  • C = 1.062 inch ( 1 1/16 inch ) diameter
  • D = 1.062 inch ( 1 1/16 inch ) diameter
  • Outside snap rings

CLICK HERE for Dana Spicer 5-213X with grease fitting in BODY

NOTE: 5-1330-1X universal joint may also fit at the front diff end of your front CV driveshaft.

  • Please measure the front diff pinion yoke carefully to see if the yoke saddles are machined for 1.062 inch u-joint bearing caps or 1.125 inch bearing caps.  Both choices are possible in 1979 to 1999 F350 trucks.
