DANA SPICER 8-2-119 Flange Yoke 1880 Series
8-2-119
DANA SPICER 8-2-119
1880 Series Flange Yoke
Shipping: >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
Pricing:
$549.73
Description
DANA SPICER 8-2-119
1880 Series Flange Yoke
- A - Flange or Swing Diameter = 9.562 inches
- B - Bolt Circle Diameter = 8.250 inches
- Bolt Hole Diameter = 0.625 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7 inches
- Center Pilot = MALE
- Series = 1880
- U-Joint Width = 8.094 inches
- D - U-Joint Bearing cap diameter = 2.188 inches
- G - Center of u-joint bore to Face of flange = 2.500 inches
- X - inches
- Y - inches
- Special Notes:
Details
- 8-2-119
- 8-2-119
- Spicer
- Available
- New
Shipping Information
- Item Requires Shipping
- 21.0 lbs.
- W10.0000” x H10.0000” x L4.0000”
