DANA SPICER 6.3-2-19 Flange Yoke 1760 Series
6.3-2-19
DANA SPICER 6.3-2-19
1760 Series Flange Yoke
Not Available
Shipping: >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
Pricing:
$268.48
Description
DANA SPICER 6.3-2-19
1760 Series Flange Yoke
- A - Flange or Swing Diameter = 8 inches
- B - Bolt Circle Diameter = 7.250 inches
- Bolt Hole Diameter = 0.438 inches
- Bolt Holes = 12
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 7.750 inches
- Center Pilot = MALE
- Series = 1760
- U-Joint Width = 7 inches
- D - U-Joint Bearing cap diameter = 1.938 inches
- G - Center of u-joint bore to Face of flange = 3.375 inches
- Special Notes:
Details
- 6.3-2-19
- 6.3-2-19
- Spicer
- Temporarily Not Available
- New
Shipping Information
- Item Requires Shipping
- 13.0 lbs.
- W8.0000” x H8.0000” x L4.0000”
