DANA SPICER 5-2-599-1 Flange Yoke 1610 Series Half Round Bearing Strap Style
5-2-599-1
DANA SPICER 5-2-599-1
1610 Series Flange Yoke
Not Available
Shipping: >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
Pricing:
$205.75
Description
DANA SPICER 5-2-599-1
1610 Series Flange Yoke
- A - Flange or Swing Diameter = 6.875 inches
- B - Bolt Circle Diameter = 6.125 inches
- Bolt Hole Diameter = 0.375 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 5.312 inches
- Center Pilot = MALE
- Series = 1610
- U-Joint Width = 5.312 inches
- D - U-Joint Bearing cap diameter = 1.875 inches
- G - Center of u-joint bore to Face of flange = 2.750 inches
- Special Notes: BEARING STRAP HALF ROUND style w/brake pilot.
Details
- 5-2-599-1
- 5-2-599-1
- Spicer
- Temporarily Not Available
- New
Shipping Information
- Item Requires Shipping
- 9.0 lbs.
- W7.0000” x H7.0000” x L3.0000”
- FREE SHIPPING ON PARTS ORDERS OVER $99
- >>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
