DANA SPICER 3-2-499 Flange Yoke 1480 Series
Part Number:
3-2-499


UPC:
023913214722
Your Cost $265.07 Sale Price $223.30
You Save $41.77
STATUS:  FACTORY DIRECT TO YOU

DANA SPICER 3-2-499

1480 Series Flange Yoke




Spicer
DANA SPICER 3-2-499 Flange Yoke 1480 Series
DANA SPICER 3-2-499 Flange Yoke 1480 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY DIRECT TO YOU
YOUR COST:  $265.07 Sale Price $223.30
You Save $41.77

DANA SPICER 3-2-499

1480 Series Flange Yoke

  • A - Flange or Swing Diameter = 6.875 inches
  • B - Bolt Circle Diameter = 6.125 inches
    • Bolt Hole Diameter = 0.386 inches
    • Bolt Holes = 8
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 6.625 inches
    • Center Pilot = MALE
  • Series = 1480
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 4.187 inches
    • D - U-Joint Bearing cap diameter = 1.375 inches
  • G - Center of u-joint bore to Face of flange = 2 inches
  • X - inches
  • Y - inches
  • Special Notes:





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 3-2-499 Flange Yoke 1480 Series

DANA SPICER 3-2-499 Flange Yoke 1480 Series
