DANA SPICER 3-2-1159 Flange Yoke 1410 Series
3-2-1159
DANA SPICER 3-2-1159
1410 Series Flange Yoke
Pricing:
$92.95
Description
DANA SPICER 3-2-1159
1410 Series Flange Yoke
- A - Flange or Swing Diameter = 4.724 inches
- B - Bolt Circle Diameter = 3.996 inches
- Bolt Hole Diameter = 0.394 inches
- Bolt Holes = 8
- Bolt Holes = DRILLED
- C - Center Pilot Hole Diameter = 2.954 inches
- Center Pilot = FEMALE
- Series = 1410
- Outside Snap Ring Style
- U-Joint Width between snap rings = 4.187 inches
- D - U-Joint Bearing cap diameter = 1.187 inches
- G - Center of u-joint bore to Face of flange = 2.531 inches
- X - inches
- Y - inches
- Special Notes: METRIC FLANGE
Details
- 3-2-1159
- 3-2-1159
- Spicer
- Available
- New
Shipping Information
- Item Requires Shipping
- 3.0 lbs.
- W5.0000” x H5.0000” x L3.0000”
