DANA SPICER 2-2-899 Flange Yoke 1210 Series

DANA SPICER 2-2-899

1210Series Flange Yoke

• A - Flange or Swing Diameter = 3.406 inches
• B - Bolt Circle Diameter = 2.750 inches
  • Bolt Hole Diameter = 0.328 inches
  • Bolt Holes = 4
  • Bolt Holes = DRILLED
• C - Center Pilot Hole Diameter = 2.250 inches

  • Center Pilot = MALE
• Series = 1210
  • Outside Snap Ring Style
  • U-Joint Width between snap rings = 2.438 inches
  • D - U-Joint Bearing cap diameter = 1.062 inches
• G - Center of u-joint bore to Face of flange = 1.484 inches
• X - inches
• Y - inches
• Special Notes:  Fits several Nissan cars and trucks up to 1986.  Must check dimensions before ordering.
