Driveshaft and Driveline Parts > HARDWARE > U-Bolts > U-Bolts for 1.375 caps

Dana Spicer 3-94-28X U-Bolt Set fits 1.375 bearing cap diameter 1.914 CL on 1480/1550 Series u-bolt style transmission, transfer case and differential pinion yokes

Part Number:
3-94-28X

UPC:

023913123055

Your Cost $16.35

STATUS: IN STOCK

DANA SPICER 3-94-28X

Fits 1.375 cap x 1.914 CL

1480 and 1550 Series Spicer U-Bolts.

Fits u-bolt style 1480 and 1550 Series transmission, transfer case and differential yokes
Fits 1.375 inch (1 3/8) universal joint bearing cap diameter
CL to CL = 1.914
Thread size = .438 - 20

Set includes:

(2) u-bolts
(4) nuts
(4) lock washers

Recommended nut Torque = 32 to 37 lb. ft.

Spicer

Dana Spicer 3-94-28X U-Bolt Set fits 1.375 bearing cap diameter 1.914 CL on 1480/1550 Series u-bolt style transmission, transfer case and differential pinion yokes

Dana Spicer 3-94-28X U-Bolt Set fits 1.375 bearing cap diameter 1.914 CL on 1480/1550 Series u-bolt style transmission, transfer case and differential pinion yokes

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK

YOUR COST: $16.35

DANA SPICER 3-94-28X

Fits 1.375 cap x 1.914 CL

1480 and 1550 Series Spicer U-Bolts.

Fits u-bolt style 1480 and 1550 Series transmission, transfer case and differential yokes
Fits 1.375 inch (1 3/8) universal joint bearing cap diameter
CL to CL = 1.914
Thread size = .438 - 20

Set includes:

(2) u-bolts
(4) nuts
(4) lock washers

Recommended nut Torque = 32 to 37 lb. ft.

Misc Parts - U-Bolt Assemblies	Model/Part #: 3-94-28X
Series	1480/1550
Thread Dia.	.438-20
C/L to C/L	1.914
Fits Brg. Cap Dia.	1.375
U-Bolt No.	3-94-29
L'washer No.	500357-12
Nut No.	231421-4
Nut Torque (lb.ft)	32-37

Dana Spicer 3-94-28X U-Bolt Set fits 1.375 bearing cap diameter 1.914 CL on 1480/1550 Series u-bolt style transmission, transfer case and differential pinion yokes

Dana Spicer 3-94-28X U-Bolt Set fits 1.375 bearing cap diameter 1.914 CL on 1480/1550 Series u-bolt style transmission, transfer case and differential pinion yokes
