CV996D Master Rebuild Kit for Front Driveshaft 2003, 2004, 2005, 2006 JEEP TJ RUBICON

CV996D

MASTER REBUILD KIT for TJ Rubicon Front Driveshaft

1330 Series NON Greaseable Double Cardan CV Driveshaft Rebuild Kit with 2 U-Joints

• Fits 2003, 2004, 2005, 2006 Jeep TJ RUBICON 1330 series OEM FRONT NON Greaseable Double Cardan CV Driveshaft
  • Use on 03 to 06 Jeep TJ RUBICON OEM or aftermarket 1330 series Front CV Driveshaft to repair or rebuild NON Greaseable Double Cardan CV Joint
• Kit Includes
  • (1) Dana Spicer 211996X Centering Yoke....NON GREASEABLE
    • Includes Spring
    • Includes (4) Grade 8 Bolts Hex Head Bolts
  • (2) Dana Spicer 5-1330X NON-GREASEABLE Universal Joints for CV
  • (1) Dana Spicer 5-793X NON-GREASEABLE Universal Joint for slip yoke
  • (1) Dana Spicer 2-86-418 Rubber Boot for CV
  • (1) 40021078 Rubber Boot for Slip Yoke

DOES NOT fit any models with 1310 series front driveshaft

DOES NOT fit OEM or aftermarket 1330 CV Driveshaft with FLAT FLANGE at TRANSFER CASE

DOES NOT fit OEM or aftermarket 1330 CV Driveshafts originally built with a Greaseable CV Centering yoke

• Centering Yoke Fits 1330 Series Universal Joint
  • Dimension between locating tabs on centering yoke is (3.625 inches) 3 5/8 inches
  • Designed to fit (1.062 inches) 1 1/16 inch U-Joint Bearing cap

JEEP TJ RUBICON ONLY
