DANA SPICER 48903 OUTER AXLE 30 spline fits 1988-1/2 to 1998 F-350 with DANA 60 FRONT

DANA SPICER 48903

• OUTER AXLE SHAFT
• Fits FORD F-350 with DANA 60 FRONT Axle

  • 1988-1/2, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998

• FITS the following axle universal joints

  • 5-806X ....old Dana Spicer part number..... see SPL55-3X
  • SPL55-3X Non Greaseable
  • SPL55-4X Greaseable
• DIMENSIONS

  • B1 = 1.31 diameter wiith 30 splines
  • B =11.4 inches Centerline of u-joint to end of yoke
  • U-Joint Snap Ring Dimension = 3 inches
  • U-Joint Bearing Cap Diameter = 1.375 inches ( 1 3/8 inches )
• SPECIAL NOTES:

  • USE 700014 and 37308 for 1988-1/2 to 1991-1/2 ....see parts listed below
  • USE 708084 for 1992 to 1998  ....see parts listed below
