DANA 60 FRONT - FORD 1975 to 2004

DANA 60 / 248

248 mm / 9.75 inch ring gear

1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004

FORD F-250, F-350, F-450, F-550
LEAF Spring FRONT ONLY
image/jpeg
  • Dana 60 front axles have been used in FORD F-250 and F-350 4x4 trucks since the mid 70's.  In 2000 Ford F-450 and F-550 4x4 models also used the Dana 60 front axles and starting in 2005 the F-450 and F-550 had the Super 60 front axles.  The Ford 4x4 Dana 60's have the drivers side drop, both standard (low pinion) and  reverse cut (high pinion) gears and kingpin steering knuckles up to about 1991 and in 1992 they started using ball joints in the steering knuckles.







Ford Dana 60 Front Exploded View



Diagram # Part # Description Diagram #
Part #
Description
 1  ****  Housing - for referrence only  33 - 53  Multiple  King Pin Parts
 2  Multiple  Ring and Pinion Gear Set  50 - 51  ****  Knuckle
 3  34643  Slinger - Inner Pinion Bearing  52  37759-2  Spindle Stud and nut
 4  706046X  Inner Pinion Bearing  56  Multiple  AXLE shaft parts
 5  708020  Shims - Diff and Pinion kit  57  Multiple  Dust shield seal retainer
 6  30982  Baffle  58 - 61  Multiple  Spindle bearing and seal kit
 7  708020  Shims - Diff and Pinion kit  62  Multiple  Spindle
 7  45658  Crush Collar  63  37759-2  Nut for spindle stud
 8  706045X  Outer Pinion Bearing  64  Multiple  Inner hub seal
 9  42737  Thrustwasher  65  Multiple  Inner wheel bearing
 10  Multiple  Pinion Seal  66  Multiple  Outer wheel bearing
 11      67  ****  Hub
 12  Multiple  Pinion Yoke  68  ****  ****
 13  ****  Slinger comes with pinion yoke  69  Multiple  Inner Nut - wheel bearing
 14  30275  Pinion Washer  70  Multiple  Washer - wheel bearing
 15  30271  Pinion Nut  71  Multiple  Outer Nut - wheel bearing
 16  Multiple  Diff Cover  72  37997  Spacer
 17  34687  Cover Gasket  73  37994  Gear
 18  ****  Plug  74  620142  Snap ring fits axle shaft
 19  34822  Cover bolts  75  620097  Snap ring fits hub
 20  ****  Diff bearing cap  76  *****  Lockout Hub
 21  ****  Cap bolt  78  Multiple  Posi clutch plate kit
 22  706047X  Diff Bearings  80  40835  Trac lok posi plate clips
 23  708020  Shims - Diff and Pinion kit  83 - 89  700238-2X  Ball Joint Set
 24  Multiple  Diff Case  90  Multiple  Seal see 50381 and 50492
 25  40638  Ring Gear Bolt  91  50491  Seal
 26  35625  Diff Large Spider Gear  92  47766  Thrustwasher
 27  34367  Diff Small Spider Gear  93  41784-2  O Ring
 28  34729  Thrustwasher  94  47816  Stud
 26, 27, 28, 29  Multiple  Spider Gear Kit  95  *****  Hub Unit Bearing
 29  34730  Cupped thrustwasher  96 - 97  701166X  Thrustwasher Kit
 30  44810  Lock pin - Open Diff and Trac Lok  98  620142  Snap Ring
 31  30263  Cross pin - Open Diff and Trac Lok
 32  Multiple  Axle tube seal




DANA 60 FRONT - FORD 1975 to 2004

AXLE PARTS

AXLE SNAP RINGS

AXLE U-JOINT

F250, F350 AXLE U-JOINT

F450, F550 AXLE U-JOINT

OUTER AXLE SHAFT

F250, F350 OUTER AXLE - 1978 - 1979 and 1985 - 1988 ONLY

F250, F350 OUTER AXLE - 1988-1/2 to 1998

F250, F350 OUTER AXLE - 1998 to 2004 LEAF SPRING FRONT

F450, F550 OUTER AXLE

INNER AXLE SHAFT

1978 to 1979 F250, F350 INNER AXLE

1985 to 1988 F350 INNER AXLE

1989 to 1998 F350 INNER AXLE

2000 to 2004 F250, F350 INNER AXLE

2000 to 2004 F450, F550 INNER AXLE

SEALS

AXLE SEALS - OUTER

THRUST WASHERS

TUBE SEALS - INNER

O RINGS

Vacuum Fitting

BALL JOINTS

Dana Spicer 700238-2X BALL JOINT SET for 2000 to 2004 F-450, F-550 with DANA 60 CLICK HERE for More Details Part Number: 700238-2X
Diagram Number:
83-89
$85.33
IN STOCK

STEERING KNUCKLE PARTS

UPPER PARTS

LOWER PARTS

DIFF PARTS

PINION NUT and WASHER

Dana 60 Pinion NUT CLICK HERE for More Details Part Number: 30271
Diagram Number:
15
$0.95
IN STOCK
Dana 60 Pinion WASHER CLICK HERE for More Details Part Number: 30275
Diagram Number:
14
$0.45
IN STOCK

RING GEAR BOLTS

BEARINGS, SHIMS, BAFFLES, SLINGERS

CRUSH SLEEVE / COLLAPSABLE SPACER

DIFF BEARINGS

DANA SPICER 706047X - FORD DANA 60 Differential Carrier Bearings (2) 382S (2) 387A CLICK HERE for More Details Part Number: 706047X
Diagram Number:
22
$88.15
$82.95
IN STOCK
TIMKEN Bearing 382S CLICK HERE for More Details Part Number: 382S
Diagram Number:
20
$25.77
IN STOCK
Timken 387A Bearing Cone CLICK HERE for More Details Part Number: 387A
$26.51
IN STOCK

DIFF MASTER BEARING KIT

DT Components DRK-331MK Master Bearing Kit fits Dana 60 Front Ford F250, F350 CLICK HERE for More Details Part Number: DRK-331MK
$199.95
$185.95
IN STOCK
FREE SHIPPING

DIFF SETUP SHIMS

DANA SPICER 708012 Differential Carrier SHIM KIT for Dana 60, 61 CLICK HERE for More Details Part Number: 708012
Diagram Number:
23
$54.53
$45.67
IN STOCK
DANA SPICER 708020 DIFF and PINION SHIM KIT for Ford with Dana 60, 61 CLICK HERE for More Details Part Number: 708020
Diagram Number:
7&23
$68.25
$63.60
IN STOCK

PINION BEARINGS

DANA SPICER 706045X - FORD DANA 60 OUTER PINION Bearing HM88510 and HM88542 CLICK HERE for More Details Part Number: 706045X
Diagram Number:
8
$32.30
$29.47
IN STOCK
DANA SPICER 706046X - FORD DANA 60 INNER PINION Bearing HM803110 and HM803146 CLICK HERE for More Details Part Number: 706046X
Diagram Number:
4
$41.95
$38.95
IN STOCK

PINION SEALS

BAFFLES, SLINGERS, THRUST WASHERS

Dana Spicer 34643 pinion oil slinger 4.5 inch OD fits Dana 60 CLICK HERE for More Details Part Number: 34643
Diagram Number:
3
$7.95
IN STOCK

Dana 60 OPEN DIFF

DANA 60 OPEN DIFF - LOADED CASE

DANA 60 OPEN DIFF - EMPTY CASE

DANA 60 OPEN DIFF - INTERNAL PARTS

Dana Spicer 30263 Cross Shaft Dana 60 Open diff and Track Lok diff case CLICK HERE for More Details Part Number: 30263
Diagram Number:
31
$16.66
IN STOCK

DIFF POSI CLUTCH PARTS

Dana Spicer 30263 Cross Shaft Dana 60 Open diff and Track Lok diff case CLICK HERE for More Details Part Number: 30263
Diagram Number:
31
$16.66
IN STOCK

Diff Cover and Gasket

Victor Reinz 70-31414-10 Reinzosil RTV Silicone Gasket Maker 2.36 oz. (70 ml) tube CLICK HERE for More Details Part Number: 70-31414-10
Diagram Number:
17
$4.94
IN STOCK
Dana Spicer 34687 DIFF COVER GASKET CLICK HERE for More Details Part Number: 34687
$4.53
IN STOCK

PINION YOKE

1310 SERIES

Neapco N2-4-3801X Pinion Yoke U-Bolt Style 1310 series fits Dana 60 with 29 spline pinion CLICK HERE for More Details Part Number: N2-4-3801X
Diagram Number:
12
$94.38
$89.89
IN STOCK

1330 SERIES

1350 SERIES

Dana 60 Pinion Yoke 1350 series 29 spline U-Bolt Style CLICK HERE for More Details Part Number: 9566266
Diagram Number:
12
$138.55
IN STOCK
FREE SHIPPING

1410 SERIES

9606112 FORGED Pinion Yoke 1410 series U-Bolt style fits all Dana 60, 61, 70 with 29 spline pinion CLICK HERE for More Details Part Number: 9606112
Diagram Number:
12
$171.55
IN STOCK
FREE SHIPPING

1480 SERIES

WHEEL BEARINGS - SEALS - SPINDLE PARTS

SPINDLES

SPINDLE BEARINGS, SEALS

Dana Spicer 37312 Thrust Washer for Dana 60 front spindle up to 1991 CLICK HERE for More Details Part Number: 37312
Diagram Number:
59
$1.44
IN STOCK
Dana Spicer 620062 Seal for Dana 60 front spindle up to 1991 CLICK HERE for More Details Part Number: 620062
Diagram Number:
60
$4.50
IN STOCK
Dana Spicer 708084 Spindle Bearing and Seal Set fits 1992 to 1998 FORD F350 with DANA 60 CLICK HERE for More Details Part Number: 708084
Diagram Number:
58-61
$53.95
$47.95
IN STOCK
Dana Spicer 37311 Rubber Seal for Dana 60 spindle fits up to 1991 CLICK HERE for More Details Part Number: 37311
Diagram Number:
58
$4.95
IN STOCK

SPINDLE STUDS

SPINDLE NUTS, WASHERS

BENDABLE TAB STYLE

PIN STYLE

WHEEL SEAL - FRONT

WHEEL BEARING - FRONT INNER

WHEEL BEARING - FRONT OUTER

DUST SHIELD for BRAKE ROTOR
