Driveshaft and Driveline Parts > BUILD IT YOURSELF - PARTS LISTS > 1310 SPLINE and SLIP DRIVESHAFT > BUILD 1310 SERIES with HD 2.125 INCH DIAMETER TUBE

2.125 x .188 DOM DRIVESHAFT TUBING - 12 INCH LENGTH

$33.00 each

View Product Details

Part Number:
2125-188-12

$33.00 each

DRIVESHAFT TUBING - DOM

12 INCH LENGTH

2.125 x .188 wall HD tubing

Each end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
- Your tube counterbore should be approximately 1.765 for tight press fit.

2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
.188 WALL THICKNESS (3/16 inch)
DOM - Drawn over mandrel
ASTM A513

Great choice for applications requiring additional torsional strength.

Also resists dents from rocks.

Status: SOLD OUT...More Coming Soon

CLICK HERE for More Details

2.125 x .188 DOM DRIVESHAFT TUBING - 24 INCH LENGTH

$66.00 each

View Product Details

Part Number:
2125-188-24

$66.00 each

DRIVESHAFT TUBING - DOM

24 INCH LENGTH

2.125 x .188 wall HD tubing

Each end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
- Your tube counterbore should be approximately 1.765 for tight press fit.

2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
.188 WALL THICKNESS (3/16 inch)
DOM - Drawn over mandrel
ASTM A513

Great choice for applications requiring additional torsional strength.

Also resists dents from rocks.

Status: SOLD OUT...More Coming Soon

CLICK HERE for More Details

2.125 x .188 DOM DRIVESHAFT TUBING - 36 INCH LENGTH

$99.00 each

View Product Details

Part Number:
2125-188-36

$99.00 each

DRIVESHAFT TUBING - DOM

36 INCH LENGTH

2.125 x .188 wall HD tubing

Each end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
- Your tube counterbore should be approximately 1.765 for tight press fit.

2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
.188 WALL THICKNESS (3/16 inch)
DOM - Drawn over mandrel
ASTM A513

Great choice for applications requiring additional torsional strength.

Also resists dents from rocks.

Status: SOLD OUT...More Coming Soon

CLICK HERE for More Details

2.125 x .188 DOM DRIVESHAFT TUBING - 48 INCH LENGTH

$132.00 each

View Product Details

Part Number:
2125-188-48

$132.00 each

DRIVESHAFT TUBING - DOM

48 INCH LENGTH

2.125 x .188 wall HD tubing

Each end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
- Your tube counterbore should be approximately 1.765 for tight press fit.
