AAM 40010355

• COLLAPSABLE SPACER - CRUSH COLLAR
• Fits GM 8.6 inch and 8.25 inch Axles
  • 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015
• 74000355
• 12479162, 01234726

AAM 14012691

• COLLAPSABLE SPACER - CRUSH COLLAR
• 74002691
• 05086702AA

AAM 26008741

• COLLAPSABLE SPACER - CRUSH COLLAR
• Fits CHEVY and GMC 10.5 inch 14 Bolt Full Floater
  • 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993,1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003
• 74008741

AAM 15552844

Pinion Nut

• GM 10.5 inch rear end
• 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998

AAM 40010207

• COLLAPSABLE SPACER - CRUSH COLLAR
• Fits CHEVY and GMC 10.5 inch Rear Axle

  • 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013
• Fits DODGE 10.5 inch Rear Axle
  • 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013
• 74000207
• 05086787AA

Full Color Poster 16 inches by 24 inches .

Dana Spicer 706014X

OUTER Pinion Bearing

• (1) Cup M86610
• (1) Cone M86647

SONNAX T3R-3-9762HP

• FORGED GM 3R series Slip Yoke
• Fits T400, 4L80, 4L85 with 32 spline rear output

Dana Spicer 708233-2

• Ring and Pinion Kit
• 4.10 Ratio (41-10) Gear Set
• 29 Spline pinion
• Fits 4.30 and DOWN Diff Carrier Case
• Fits Dana 60 REVERSE ROTATION FRONT
• COLLAPSABLE SPACER STYLE

Fits:

• FORD F350 - 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011
• FORD F450 - 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011
• FORD F550 - 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

Dana Spicer 80754

DIFFERENTIAL TRAC LOK POSI CASE ASSEMBLY

• Factory Replacement Limited Slip Positraction
• 9.25 inch Chrysler DODGE REAR

  • DODGE Ram 1500/2500, D150/250, Van 3500, W150/250, B150/250/350, Dakota, Durango all with 9.25 inch REAR

    • 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993,1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010
  • Fits all gear ratios 3.21 to 4.56
  • Use with 31 Spline "C" Clip axles
• OE Numbers
  • 75102X
  • 84751
  • 5161549AA
  • 4137425
  • 4384287
  • 52068450
  • 52069978AA
  • 52111420AA

NEAPCO 10-0413

PTO END YOKE .75 ROUND BORE WITH .188 KEY

1000 SERIES

AAM 19256728  (40085102), (7064399)

Fits AAM Front 1355 series CV Driveshaft DODGE 2500 and 3500

1355 Series U-Joint.

• Fits 2003 AND NEWER DODGE 2500 FRONT CV DRIVESHAFT applications with 1355 Series AAM American Axle built driveshafts
• Fits 2003 to 2006 DODGE 3500 FRONT CV DRIVESHAFT applications with 1355 Series AAM American Axle built driveshafts
• AAM 1355 series dimensions
  • Dimension A & B = 3.622 inches wide in both directions
  • Dimension C & D = All 4 bearing caps are 1.188 inch diameter
  • Outside snap rings

Neapco N2-4-FD01X

• Ford 9 inch Pinion Yoke
  • Fits all Ford 9 inch rear ends with 28 spline pinion gear
• 1310 series
• 28 splines
• 4 inches tall
• U-Bolt style

Fits universal joint 3.219 cap to cap with 1.062 Bearing caps

DIMENSIONS

• SPLINE OD = 1.235
• D = 1.062
• E = 3.219
• Q = 2.42
• R = 1.81
• S = 4.03

NEAPCO N3R-82-1181

GM AutoTrac NVG 246 FRONT Driveshaft Yoke Shaft fits 1999 and newer GM 4x4

3R Series Transfer Case Splined Yoke Shaft

DANA SVL 2020799

• RING AND PINION GEAR SET
• 3.73 RATIO
• D44-373F
• REVERSE ROTATION
• Fits FORD DANA 44 FRONT ONLY
• 26 SPLINE PINION
• FITS 3.73 and DOWN DIFF CASE
• GENUINE DANA SVL GEAR SET

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

DANA SVL 2020874

• RING AND PINION GEAR SET
• 3.54 RATIO
• D60-354
• Fits DANA 60 FRONT or REAR
• Fits 4.10 and DOWN DIFF CASE
• 29 SPLINE PINION
• GENUINE DANA SVL GEAR SET

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

DANA SVL 2020523

• RING AND PINION GEAR SET
• 3.73 RATIO
• F10.25-373L
• Fits FORD 10.25 INCH REAR
• Fits F350 and F450

  • 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015
• 31 SPLINE PINION
• GENUINE DANA SVL GEAR SET

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

Dana Spicer 706017-1X

• Ring and Pinion Kit
• 3.07 Ratio (43-14) Gear Set
• 26 Spline Pinion
• Fits 3.73 and DOWN Diff Carrier Case
• Fits Dana 44 STANDARD ROTATION
• Fits Front or Rear

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

DANA SPICER 2-4-2611X

• 1.250 - 10 spline
• 1310 series
• U-Bolt style

AAM Part Number 40010627

NUT for Outer Axle Stub Shaft

OEM Dodge 9.25 inch AAM American Axle

Fits Dodge Ram 2500 and 3500 with AAM 9.25 inch front end

NEAPCO 7-0079

Jeep Rubicon FRONT CV Driveshaft Centering Yoke 1330 Series Includes 4 Grade 8 Bolts and spring

• Fits RUBICON with 1330 Series CV Driveshaft
• Fits ALL with 3 5/8 inches between Tabs in centering Yoke

DANA SVL 2020585

• RING AND PINION GEAR SET
• STANDARD ROTATION
• 3.54 RATIO
• D30-354
• 26 SPLINE PINION
• GENUINE DANA SVL GEAR SET
• Fits DANA 30 FRONT or REAR in the following vehicles:
  • FORD Aerostar
  • FORD Bronco
  • IHC Scout
  • JEEP CJ

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

DANA SVL 2020455

• RING AND PINION GEAR SET
• 4.09 RATIO
• D44-409F
• REVERSE ROTATION
• Fits FORD DANA 44 FRONT ONLY
• 26 SPLINE PINION
• FITS 3.92 and UP DIFF CASE
• GENUINE DANA SVL GEAR SET

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

NEAPCO 1-0298

DANA SVL 2019335

• RING AND PINION GEAR SET
• 4.88 RATIO
• D44-489F
• REVERSE ROTATION
• Fits FORD DANA 44 FRONT ONLY
• 26 SPLINE PINION
• FITS 3.92 and UP DIFF CASE
• GENUINE DANA SVL GEAR SET

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

NEAPCO 3-0332

NEAPCO N2-40-1701-2

SPLINE Fits 2.0 inch .120 wall tubing

• Fits any series 16 Spline SLIP YOKE designed for 1.375 inch diameter spline
• Fits TUBE DIAMETER = 2.0 inch OUTSIDE TUBE Diameter
• Fits TUBE WALL THICKNESS =  .120 inch Tube wall thickness
• Major SPLINE Diameter = 1.375
• SPLINES = 16
• K = 7.750
• L = 6.250
• R = 7.250


See listing below for suggested slip yokes

• 1310 series ... N2-3-8021KX or 2-3-8021KX
  • plus additional 280195 splined press on seal or rubber boot 211932X
• 1330 series ... N2-3-8041KX or 2-3-8041KX
  • plus additional 280195 splined press on seal or rubber boot 211932X
• 1350 series ...3-3-2591KX comes with splined seal
• 1350 series ...N3-3-1502KX comes with splined seal

DANA SVL 2020452

• RING AND PINION GEAR SET
• 5.13 RATIO
• D44-513F
• REVERSE ROTATION
• Fits FORD DANA 44 FRONT ONLY
• 26 SPLINE PINION
• FITS 3.92 and UP DIFF CASE
• GENUINE DANA SVL GEAR SET

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

DANA SPICER 2014835

AXLE HOUSING OUTER TUBE SEAL

FORD SUPER DUTY F-250, F-350, F-450, F-550 with DANA SUPER 60 FRONT AXLE

• 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013
• 2014 and 2015 DO NOT REQUIRE this seal

Replaces 2005932 and 53877

Neapco 4x4 Front Axle U-joint.  Maintenance Free.

Fits 2003 to 2009 Dodge 9.25 inch Front with AAM  Front Axles (American Axle)

Neapco 4x4 Front Axle U-joint.

NEAPCO 3-1557

DANA SVL 2020458

• RING AND PINION GEAR SET
• 5.38 RATIO
• D44-538F
• REVERSE ROTATION
• Fits FORD DANA 44 FRONT ONLY
• 26 SPLINE PINION
• FITS 3.92 and UP DIFF CASE
• GENUINE DANA SVL GEAR SET

FREE GROUND Shipping**

**Free Ground Shipping to lower 48 States ONLY...Alaska and Hawaii at reduced rates.

AAM Part Number 26060975

PINION SEAL SLEEVE

• Use AAM 26060975 PINION SEAL SLEEVE with AAM 40017140 Triple lip seal
• Dodge Ram 2500, 3500 with AAM 9.25 inch FRONT

AAM Part Number 26064029

PINION SEAL

• Fits 1998 to 2012 CHEVY and GMC with 9.5 inch 14 bolt REAR Axle
• 74004029
• Triple lip seal design

  • Requires Sleeve 26060975

AAM Part Number 40007712

PINION SEAL

• Fits CHEVY and GMC with 9.25 inch Clamshell FRONT Axle
  • 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014
• 12471590

AAM Part Number 74010011

MASTER INSTALL KIT

• Fits Chevy GM Sierra, Silverado, Yukon XL, Avalanche, Hummer H2 with AAM 9.25 inch Salisbury Front Axle

  • 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016
• SET INCLUDES
  • (2) OUTPUT SEALS 40051283 / 19169124
  • (2) SNAP RINGS 40040610
  • (1) VENT CONNECTOR 40026655
  • (1) VENT CONNECTOR H2 ONLY 46002040
  • (5) TUBE BOLTS WITH WASHERS and ADHESIVE 26036835
  • (1) ROLLER BEARING ASM I/O 26041516
  • (1) ROLLER BEARING ASM I/O 15530296
  • (2) ROLLER BEARING ASM 7401873 / 15521873
  • (2) DIFFERENTIAL ADJUSTER LOCK 15521875
  • (1) ADJUSTER LOCK WASHER 11503963
  • (20) OUTPUT SHAFT SHIMS
  • (11) CARRIER BOLT WITH WASHERS AND ADHESIVE 14045736
  • (18) PINION SHIMS
  • (1) FILL / DRAIN PLUG MAGNETIC 26058815
  • (2) FILL / DRAIN PLUG WASHER 14042602
  • (1) FILL / DRAIN PLUG WASHER 476753
  • (1) COLLAPSABLE SPACER 74002691 / OE Number 14012691
  • (1) THRUST WASHER 40051849
  • (1) PINION NUT 74003762 / OE Number 9783762
  • (1) PINION NUT WASHER 74007900 / OE Number 517900
  • (12) RING GEAR BOLT W/ ADHESIVE 74002703 / OE Number 14012703
  • (1) SNAP RING 26031703
  • (1) SNAP RING 15521872
  • (1) ADJUSTER BOLT 11503877
  • (1) PINION SEAL 40007712
  • (1) VIEW PLUG ASSEMBLY 40027570
  • (2) DOWEL PIN 360570
  • (1) RUBBER OVER METAL COVERPAN GASKET 40058296
  • (12) COVERPAN BOLT W/ ADHESIVE 40002169
  • (12) RING GEAR BOLT W/ ADHESIVE 74002703 / OE Number 14012703
  • (1) COLLAPSABLE SPACER 74002691 / OE Number 14012691

AAM Part Number 74010010

MASTER INSTALL KIT

• Fits Chevy GM Sierra , Silverado with AAM 9.25 inch Salisbury Front Axle
  • 2010, 2011, 2012, 2013, 2014, 2015, 2016
• SET INCLUDES
  • (6) TUBE BOLTS WITH WASHERS and ADHESIVE
  • (2) OUTPUT SEALS
  • (1) RUBBER OVER METAL COVERPAN GASKET 40058296
  • (12) COVERPAN BOLT W/ ADHESIVE 40002169
  • (12) RING GEAR BOLT W/ ADHESIVE 74002703 / OE Number 14012703
  • (1) COLLAPSABLE SPACER 74002691 / OE Number 14012691
  • (1) PINION NUT 74003762 / OE Number 9783762
  • (1) PINION NUT WASHER 74007900 / OE Number 517900
  • (18) PINION SHIMS
  • (1) PINION SEAL 40007712 / OE Number 12471590
  • (1) FILL / DRAIN PLUG 40039752
  • (1) THRUST WASHER 40051849
  • (20) OUTPUT SHIMS
  • (2) LOCK RINGS 40058278
  • (3) ROLLER BEARING ASM 7401873 / 15521873
  • (1) ROLLER BEARING ASM I/O 26041516
  • (1) TUBE GASKET 40058297
  • (1) VENT CONNECTOR 46002040
  • (2) SNAP RINGS 40040610
