DANA SPICER 3-2-609 Flange Yoke 1480 Series REPLACED by 3-2-479
Part Number:
3-2-609


UPC:
Your Cost $115.39
Sorry, sold out
STATUS:  Discontinued Item...See other choices listed

DANA SPICER 3-2-609

1480 Series Flange Yoke

REPLACED by 3-2-479




Spicer
DANA SPICER 3-2-609 Flange Yoke 1480 Series REPLACED by 3-2-479
DANA SPICER 3-2-609 Flange Yoke 1480 Series REPLACED by 3-2-479
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  Discontinued Item...See other choices listed
YOUR COST:  $115.39

DANA SPICER 3-2-609

REPLACED by 3-2-479

1480 Series Flange Yoke

  • A - Flange or Swing Diameter = 5.875 inches
  • B - Bolt Circle Diameter = 4.750 inches
    • Bolt Hole Diameter = 0.500 inches
    • Bolt Holes = 4
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 3.750 inches
    • Center Pilot = MALE
  • Series = 1480
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 4.187 inches
    • D - U-Joint Bearing cap diameter = 1.375 inches
  • G - Center of u-joint bore to Face of flange = 2 inches
  • X - inches
  • Y - inches
  • Special Notes:





Denny's Driveshafts Flange Yoke Dimension Diagram

DANA SPICER 3-2-609 Flange Yoke 1480 Series REPLACED by 3-2-479

DANA SPICER 3-2-609 Flange Yoke 1480 Series REPLACED by 3-2-479
