DANA SPICER 1-26-297 Weld Yoke 1100 Series to fit 1.25 inch .095 wall tubing
Part #:
1-26-297
Your Cost $58.95

DANA SPICER 1-26-297

1100 Series Weld Yoke

Spicer
DANA SPICER 1-26-297 Weld Yoke 1100 Series to fit 1.25 inch .095 wall tubing
DANA SPICER 1-26-297 Weld Yoke 1100 Series to fit 1.25 inch .095 wall tubing
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $58.95

DANA SPICER 1-26-297

1100 Series Weld Yoke

  • Fits 1.25 inch OD X .095 wall tubing
    • F - Butt Diameter = 1.068
  • Series = 1100
  • Lock up style = OUTSIDE SNAP RING
  • E - Universal Joint Width = 2.411
  • D - Universal Joint Bore = .938
  • H - Center of u-joint bore to point of weld = 1.688
  • Special Notes: USE KIT 5-101X



CLICK HERE : For ALL DANA SPICER Weld Yoke Part Numbers, Specifications and Dimensions

image/jpeg
DANA SPICER 1-26-297 Weld Yoke 1100 Series to fit 1.25 inch .095 wall tubing

DANA SPICER 1-26-297 Weld Yoke 1100 Series to fit 1.25 inch .095 wall tubing

You May Also Need These Parts to Complete the Job

DANA SPICER 5-101X PTO Universal Joint 1100/1110 Series for Power Take Off
$17.95
