Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck


Driveshaft and Driveline Parts > Universal Joints > COMBINATION-CONVERSION U-Joints > Combo U-Joint 1350 to 3R series 3.625 OUTSIDE to 2.562 INSIDE > 1.188 X 1.125 Bearing Cap Diameter

Dana Spicer 5-3205X Combination U-joint converts 1350 Series to GM 3R Series GREASEABLE
Part Number:
5-3205X


UPC:
023913126209
 Your Cost $41.35
STATUS:  IN STOCK

Dana Spicer 5-3205X

NOTE:  This universal joint is actually a Neapco U-Joint in the Dana Spicer box.  They are doing this until they tool up to actually make this part in the Dana factory.  It is a very good quality universal joint that will deliver excellent performance and it will fit correctly.

  • Combination Universal Joint
    • Converts Outside snap ring 1350 series to Inside "C" clip style GM 3R Series
    • Greaseable universal joint - fitting in body
    • Requires regular maintenance intervals for long life
  • 1350 series dimensions
    • Dimension B = 3.625 inches (3 5/8) wide
    • Dimension D = 2 bearing caps are 1.187 inch diameter
    • outside snap rings
  • GM 3R series dimensions
    • Dimension A  = 2.562 inches (2 9/16) wide
    • Dimension C = 2 bearing caps are 1.125 inch diameter with inside "C" Clips to lock the cap in place.
    • inside "C" Clips
    • The span between the yoke inner surfaces where the "C" Clips lock in is 2.556 inches
Spicer
Dana Spicer 5-3205X Combination U-joint converts 1350 Series to GM 3R Series GREASEABLE
Dana Spicer 5-3205X Combination U-joint converts 1350 Series to GM 3R Series
Click for Larger Photo
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  IN STOCK
YOUR COST:  $41.35

Dana Spicer 5-3205X

NOTE:  This universal joint is actually a Neapco U-Joint in the Dana Spicer box.  They are doing this until they tool up to actually make this part in the Dana factory.  It is a very good quality universal joint that will deliver excellent performance and it will fit correctly.

  • Combination Universal Joint
    • Converts Outside snap ring 1350 series to Inside "C" clip style GM 3R Series
    • Greaseable universal joint - fitting in body
    • Requires regular maintenance intervals for long life
  • 1350 series dimensions
    • Dimension B = 3.625 inches (3 5/8) wide
    • Dimension D = 2 bearing caps are 1.187 inch diameter
    • outside snap rings
  • GM 3R series dimensions
    • Dimension A  = 2.562 inches (2 9/16) wide
    • Dimension C = 2 bearing caps are 1.125 inch diameter with inside "C" Clips to lock the cap in place.
    • inside "C" Clips
    • The span between the yoke inner surfaces where the "C" Clips lock in is 2.556 inches
