Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

Neapco 1-0024 strap and bolt set fits Tab Style GM 7.5, 8.2, 8.5 inch 10 Bolt and Chevy 12 bolt with 1310/1330 Tab Style Pinion Yoke designed for 1.062 bearing cap
Part Number:
1-0024


UPC:
083869100241
Your Cost $9.20 Sale Price $8.36
You Save $0.84
Sorry, sold out
STATUS:  Discontinued Item...See other choices listed

NEAPCO 1-0024

  • 1310-1330 Series Strap & Bolt Set
  • Fits GM 7.5, 8.2 and 8.5 inch 10 Bolt with 1310/1330 Tab Style Pinion Yoke
  • Fits Chevy 12 Bolt with 1310/1330 Tab Style Pinion Yoke
    • Fits 1.062 bearing caps
    • Also fits 1330 series Corvette T-400 detachable transmission slip yoke.
  • Strap and bolt set comes with (2) Straps (4) 5/16 fine thread Bolts.
  • Replace that old stretched out original set with a new one.
  • Same as Dana Spicer 2-70-28X

Neapco
Neapco 1-0024 strap and bolt set fits Tab Style GM 7.5, 8.2, 8.5 inch 10 Bolt and Chevy 12 bolt with 1310/1330 Tab Style Pinion Yoke designed for 1.062 bearing cap
Neapco 1-0024 strap and bolt set fits Tab Style GM 7.5, 8.2, 8.5 inch 10 Bolt and Chevy 12 bolt with 1310/1330 Tab Style Pinion Yoke designed for 1.062 bearing cap
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  Discontinued Item...See other choices listed
YOUR COST:  $9.20 Sale Price $8.36
You Save $0.84

NEAPCO 1-0024

  • 1310-1330 Series Strap & Bolt Set
  • Fits GM 7.5, 8.2 and 8.5 inch 10 Bolt with 1310/1330 Tab Style Pinion Yoke
  • Fits Chevy 12 Bolt with 1310/1330 Tab Style Pinion Yoke
    • Fits 1.062 bearing caps
    • Also fits 1330 series Corvette T-400 detachable transmission slip yoke.
  • Strap and bolt set comes with (2) Straps (4) 5/16 fine thread Bolts.
  • Replace that old stretched out original set with a new one.
  • Same as Dana Spicer 2-70-28X

Fits BEARING SIZE: 1.062
BOLT HOLE DIAMETER: 0.312
CL TO CL: 1.593
Fits SERIES: 1310 / 1330
BOLT LENGTH UNDER HEAD: 1.500
STRAP WIDTH: 0.620
THREAD SIZE: 0.312 - 24 (5/16 diameter)



Be sure to replace your existing strap and bolt set to eliminate the chance of the u-joint cap rotating in the pinion yoke and permanently damaging it.  When this happens the damage to the pinion yoke usually allows the universal joint to move from side to side within the yoke and the resulting looseness will surely cause a nagging vibration. The strap is designed to conform to the shape of the universal joint bearing cap when the bolts are tightened to the proper torque spec and is also designed to apply the proper amount of pressure to hold the bearing cap from rotating within the yoke.

Reusing the straps many times will lessen their ability to apply the right holding pressure....this is why you should replace them...it's much cheaper and easier to replace than a new pinion yoke.



Neapco 1-0024 strap and bolt set fits Tab Style GM 7.5, 8.2, 8.5 inch 10 Bolt and Chevy 12 bolt with 1310/1330 Tab Style Pinion Yoke designed for 1.062 bearing cap

Neapco 1-0024 strap and bolt set fits Tab Style GM 7.5, 8.2, 8.5 inch 10 Bolt and Chevy 12 bolt with 1310/1330 Tab Style Pinion Yoke designed for 1.062 bearing cap
