Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

Dana Spicer 3-40-1571 SPLINE Fits 3.5 inch .083 wall Driveshaft tubing 1.562 inch Diameter with 16 Splines
Part #:
3-40-1571
Your Cost $79.95

DANA SPICER 3-40-1571 SPLINE

Fits 3.5 inch .083 wall Driveshaft tubing

1.562 inch Diameter with 16 Splines



Spicer
Dana Spicer 3-40-1571 SPLINE Fits 3.5 inch .083 wall Driveshaft tubing 1.562 inch Diameter with 16 Splines
Dana Spicer 3-40-1571 SPLINE Fits 3.5 inch .083 wall Driveshaft tubing 1.562 inch Diameter with 16 Splines
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY DIRECT TO YOU
YOUR COST:  $79.95

DANA SPICER SPLINE 3-40-1571

  • Fits any series 16 Spline SLIP YOKE designed for 1.562 inch diameter spline
  • Fits TUBE DIAMETER = 3.5 inch OUTSIDE TUBE Diameter
  • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
  • Major SPLINE Diameter = 1.562
  • SPLINES = 16
  • K = 6.750
  • L = 3.0
  • R = 5.810
