Denny's Driveshaft builds custom steel and aluminum driveshafts for your high performance car, street rod, race car, van, pick up or 4x4 truck

DANA SPICER 90-2-49-1 Flange Yoke SPL90 Series
Part Number:
90-2-49-1


UPC:
023913248369
Your Cost $178.45 Sale Price $150.33
You Save $28.12
STATUS:  FACTORY DIRECT TO YOU

DANA SPICER 90-2-49-1

SPL90 Series Flange Yoke




Spicer
DANA SPICER 90-2-49-1 Flange Yoke SPL90 Series
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY DIRECT TO YOU
YOUR COST:  $178.45 Sale Price $150.33
You Save $28.12

>>>>> SPECIAL ORDER PART:  This part number is special ordered from the factory and shipped direct to you.  It is NOT Cancellable and NOT Returnable.  Please make your selection carefully! <<<<<

DANA SPICER 90-2-49-1

SPL90 Series Flange Yoke

  • A - Flange or Swing Diameter = 6.688 inches
  • B - Bolt Circle Diameter = 6.124 inches
    • Bolt Hole Diameter = 0.375 inches
    • Bolt Holes = 8
    • Bolt Holes = DRILLED
  • C - Center Pilot Hole Diameter = 5.312 inches
    • Center Pilot = MALE
  • Series = SPL90
    • Outside Snap Ring Style
    • U-Joint Width between snap rings = 4.957 inches
    • D - U-Joint Bearing cap diameter = 1.625 inches
  • G - Center of u-joint bore to Face of flange = 2.750 inches
  • Special Notes: B.S./H.R.style w/brake pilot.





Heavy duty truck and equipment driveshaft flange yokes at Denny's Driveshafts

DANA SPICER 90-2-49-1 Flange Yoke SPL90 Series
